Zebra L10 Android Tablet Vehicle Docking Station (5x RF-SMA)

• SMA - (WWAN Main, GPS, WWAN Aux, WIFI Main, WIFI Aux)

COMPATIBILITY

• Zebra L10 Android XSLATE or XPAD tablet computer

• Zebra Certified Electronics
• USB 2.0 (2) - 9 pin (900mA)
• USB 2.0 (2) - 4 pin (500 mA)
• USB 2.0 (1) - 4 pin (500mA) behind internal access door
• RS232 Serial (1) - Power on pin 9 (switch)
• Microphone
• Headphones / Speakers
• Power Input 19Vdc

• Compatible with the Zebra L10 ANDROID xPad and xSlate tablets
• Docking Station design accommodates the L10 Extended battery, Smart Card/CAC Reader module, True Serial(RS232) module, Hard handle, Soft handle, and Shoulder Strap.
• Sealed docking connector to protect against moisture
• RS232 pin 9 function switch, activate switch to power pin 9 (5V)
• LED indicator lights show when "tablet is docked" and "dock is powered"
• Access door to internal USB 2.0 port provides additional security
• Floating docking connector for reliable docking activation
• Bottom-facing I/O ports; integrated cable restraint/cable management system
• Forward facing docking latch/release for easy one handed operation
  • Insert bottom of computer into docking station, push top of computer in and pull latch forward until latch engages
  • To remove, lift latch to disengage and pull computer out of docking station
• Keyed alike lock for security and theft deterrence
• VESA 75mm and 50 x 100mm mounting patterns
• Rounded edges to enhance personal safety
• Composite/aluminum design for reduced weight and durability
• RF pass-through SMA - (WWAN Main, GPS, WWAN Aux, WIFI Main, WIFI Aux)
• Height: 10.63 in / 27 cm
• Width: 11.81 in / 30 cm
• Depth: 3.94 in / 10.01 cm

Power Supply is NOT included, utilize one of the following:

• LIND 12-16V Automotive Power Adapter with Bare Wire Lead (7300-0484)
• LIND 12-16V Automotive Power Adapter with Cigarette Lighter Connection (7300-0345)
• LIND 12-32V Automotive Power Adapter with Bare Wire Lead (7300-0344)
• LIND 12-32V Isolated Power Adapter with Bare Wire Lead (7300-0457)
• LIND 72-110V Isolated Material Handling Power Adapter (7300-0346)
• LIND 20-60V Isolated Material Handling Power Adapter (7300-0458)

• Zebra Certified
• MIL-STD 810G Shock/Vibration Tested
• MIL-STD 810G Environmental Testing: Humidity, High/low temperature (storage/operational), Thermal Shock
• SAE J1455 Crash Tested
• Cycle Tested: 30K cycles, docking connector, latching & locking mechanisms
• RoHS, FCC, CE Certifications

• Zebra L10 Android 5X RF Docking Station
• Mounting Hardware
• Installation Instructions

• 3-Year Limited Warranty
